OPM-209C Power Meter + Laser Source Handheld Optical Multimeter
OPM-209C Optical Power Multimeter is the integration of power meter and light source, which has the function of recording, storing and uploading the data tested by the instrument. It is widely used in fiber-optic line project construction, testing and maintenance, such as digital data network, telecommunication network and cable television.
OPM Wavelength | 850/1300/1310/1490/1550/1625nm | OPM Measurement Range | -50~+26dBm |
Uncertainty | ≤±0.25dB | Linearity | ≤±0.1dB |
OLS Wavelength | 1310/1550nm | OLS Typical Output Power | > -5dBm |
OLS Modulation | CW 270/1K/2KHz | OLS Stability | ≤0.1dB |
Operation Temperature | -10~+60°C | Storage Temperature | -25~+70°C |
Dimension | 175x90x44.5mm | Weight | 265g |
